DeepCool DA700 80 Plus Bronze Certified 700W Power Supply

Deepcool
  • 80 PLUS Bronze certified offers lower heat generation and better efficiency
  • Integrated active PFC/PWM combo controller for less power loss and a higher power factor over 99%
  • Silent high performance 120mm PWM fan
  • Compact 140mm PSU length for space contrained builds
  • CircuitShield Protection – OVP, UVP, SCP, OPP
  • High Reliability MTBF of 100,000 hours

 13,600.00

DeepCool DA700 80 Plus Bronze Certified 700W Power Supply, ATX12V, 120mm PWM Silent Fan

Description

DA700 is certified with 80 plus bronze with up to 85% electrical efficiency enabling lower heat generation and lower operation cost. Outstanding and stable performance makes it one of the ideal choices for multi-purpose usage. Double layer EMI filters protect from magnetic interference and restrains noise while operating.

Silent and High Performance Fan

120mm silent fan to provide incredible performance-noise ratio.

80PLUS BRONZE

80PLUS Bronze certified provide high energy efficiency up to 85%.

Output of DeepCool DA700

AC INPUT VOLTAGE CURRENT FREQUENCY
100-240V 5-10A 47-63Hz
DC OUTPUT +3.3V +5V +12V -12V +5VSB
CURRENT(Max) 22A 18A 54A 0.3A 2.5A
OUTPUT(Max) 130W 648W 3.6W 12.5W
TOTAL OUTPUT 700W

Brand

Technical Spec of DeepCool da700 Power Supply

Model DA700
Type ATX 12V V2.4
Certifications 80PLUS Bronze
Dimension 150×140×86mm (W x L x H)
Output Capacity 700W
Input Voltage 100~240V
Input Current 10A
Input Frequency Range 47~63Hz
Fan Size 120mm Silent Fan
PFC Active PFC (>0.99)
Power Good Signal 100-500ms
Hold Up Time >16ms
Efficiency 85% Under Typical Load
Protection OVP / UVP / SCP / OPP
Operation Temperature 0~40°C
Regulatory CE / FCC / CCC / CB / EAC
MTBF 100,000 Hours
